Feature:

High stability multi-wavelength single-(multi) mode output, CW mode or modulation

Large LCD displays status of the operating wavelength

Continuous working time of up to 45 hours

Provided upon request 2 stable output wavelengths 1310 / 1550 is ideal for fiber optic test instrument works

Specification

Wavelength Range

1310 / 1550 Dual wave

Emitter Type

FP-LD,LED

Optical Connector

FC/PC

Modulation Frequencies

CW, 270Hz,1KHz,2Hz

Typical Output Power (dBm)

-7dBm for LD

Fiber Type

SM, MM

Operating Temperature（℃）

-10～+70

Working time

45 hours

Auto-off time

10min

Dimension（mm）

190*100*48mm

Power Supply

AAA 1.5V Battery x 3pcs

Weight

400g
